Pressure gauge 50 mm, TYPE -TM-210R, M12x1.5 (bottom), 0-1.0MPa (attorney)

$0.01

Characteristics
Pressure gauge TM-210R.00(0-6MPa) M12x1.5.2.5

Case diameter: 50mm;

Connection thread: M12*1.5, G1/4;

Pressure reading range, MPa: 0…6;

Accuracy class: 2.5

Working ranges:

constant load – 3/4 scale;

variable load – 2/3 scale;

short-term load: 110% scale;

Operating temperature range:

environment – -60…+60°С

measured medium – up to 150°С

Housing: IP40, steel, black;

Sensing element, tribco-sector mechanism: copper alloy;

Dial: aluminum, black scale on a white background;

Glass: mineral;

Fitting: copper alloy;

Type of connection: radial or axial;

Steel grade: body, ring – steel 10.

Similar pressure gauges from other manufacturers:
<

SKU: d45915e85833 Category: Tags: ,

Characteristics
Pressure gauge TM-210R.00(0-6MPa) M12x1.5.2.5

Case diameter: 50mm;

Connection thread: M12*1.5, G1/4;

Pressure reading range, MPa: 0…6;

Accuracy class: 2.5

Working ranges:

constant load – 3/4 scale;

variable load – 2/3 scale;

short-term load: 110% scale;

Operating temperature range:

environment – -60…+60°С

measured medium – up to 150°С

Housing: IP40, steel, black;

Sensing element, tribco-sector mechanism: copper alloy;

Dial: aluminum, black scale on a white background;

Glass: mineral;

Fitting: copper alloy;

Type of connection: radial or axial;

Steel grade: body, ring – steel 10.

Similar pressure gauges from other manufacturers:
<

Weight 1 kg
Dimensions 11 × 1 × 1 cm
