For regulating gas pressure in bars
Control Scheme Single-stage
Gas：Oxygen
Maximum input pressure：15 MPa/150bar
Maximum throughput：50 m3/h
Input Connection： G3/4″ DIN9 (Sliding Nut)
Output connection： M16x1.5 (External thread) + nipple Ø 6.3/F9.0 mm
Pressure gauge size (diameter)： 50 mm
Shut-off valve ：No
Body Material ：Brass
Maximum working pressure： 1.25 MPa/12.5 bar
Metal Body Cover
Non-adjustable safety valve provides passive protection;
Convenient handle (flywheel, adjusting screw);
Color identification by type of gas, in accordance with the Russian standard;
Climatic performance allows to use the reducer in the temperature range from -25 ° C to +50 ° C;
